THERMALEX®Commercial-Industrial Sectional Overhead Doors

THE COMPLETE SOLUTION FOR QUALITY, VERSATILITY & ENERGY EFFICIENCY.

Constructed from the highest quality materials, the Thermalex® Series is specifically designed for commercial and industrial applications – delivering remarkable performance, long-lived durability, outstanding utility features and excellent energy efficiency.

Not only does the Thermalex® Series represent exceptional value at purchase, it helps save money by preventing heat loss during its long lifespan. Thermalex® is available as a complete system that includes track, hardware and springs.

Designed for Commercial & Industrial Applications.

This product is an ideal choice for applications that demand the highest levels of thermal efficiency, protection against air infiltration and wind load resistance.

Key Benefits:

  • Environmentally friendly CFC/HCFC free foamed-in-place polyurethane insulation provides maximum R-values, excellent energy efficiency and are LEED compliant
  • Two continuous strip hinge reinforcement (TX450, TX450-20, TX500, TX500-20) permits the use of full hinge application
  • Thermal break chemically sealed and bonded
  • Design options available on some models for wind loads up to 209 km/h (130 mph)
Thickness
Product Type
1-1/2″
(38.1mm) Insulated
Foamed-In-Place
1-3/4″
(44.5mm) Insulated
Foamed-In-Place
1-3/4″
(44.5mm) Insulated
Foamed-In-Place
2″
(50.8mm) Insulated
Foamed-In-Place
2″
(50.8mm) Insulated
Foamed-In-Place
Upwardor
Model #
Thermalex
TX380
Thermalex
TX450
Thermalex
TX450-20
Thermalex
TX500
Thermalex
TX500-20
Paint/Delamination Warranty
(Finish / cracking / rust through)
5 Year limited 10 Year limited 10 Year limited 10 Year limited 10 Year limited
Hardware / Spring Warranty 1 Year 1 Year 1 Year 1 Year 1 Year
Insulation Type /
Foam Process
Polyurethane /
Continuous
Polyurethane /
Continuous
Polyurethane /
Continuous
Polyurethane /
Continuous
Polyurethane /
Continuous
R-Value
(Calculated)
14.1 16.3 16.3 18.4 18.4
Thermal Break
(Between exterior & interior skins)
Chemically Bonded
& Sealed
Chemically Bonded
& Sealed
Chemically Bonded
& Sealed
Chemically Bonded
& Sealed
Chemically Bonded
& Sealed
Section Joint Shiplap
w/ bubble weather seal
Tongue and Groove Tongue and Groove Tongue and Groove Tongue and Groove
Gauge Steel Skin
(G60 Steel: exterior)
26 / 26 26 / 26 20 / 26 20 / 26 20 / 26
Hinge Plate
(Reinforcement strip)
Single Continuous
1-1/4″ 20ga Strip
Two Continuous
1-1/4″ 20ga Strip
Two Continuous
1-1/4″ 20ga Strip
Two Continuous
1-1/4″ 20ga Strip
Two Continuous
1-1/4″ 20ga Strip
End Stiles
(20ga are standard)
20ga Galvanized 20ga or 16ga Galvanized 20ga or 16ga Galvanized 20ga or 16ga Galvanized 20ga or 16ga Galvanized
Colours Available
(Interior always white)
Bright White /
Brown
Bright White /
Brown / Silver
Bright White ONLY Bright White ONLY Bright White ONLY
Panel Appearance
(Texture)
Shallow Horz. Ribs
(Stucco embossed)
Shallow Horz. Ribs
(Stucco embossed)
Flush
(Stucco embossed)
Shallow Horz. Ribs
(Stucco embossed)
Flush
(Stucco embossed)
FULL VIEW Aluminum Sections N/A Available – V130G Insul Sealed Glass
Painted – white, brown or clear anodized
Available – V130G Insul Sealed Glass
Painted – white
N/A N/A

Window Inserts

thermalex window inserts - upwardor

Colour Options

thermalex door colour palette
